Product Information
Short Product Description
Elevate your technical laboratory benches and industrial control panels with our high-accuracy Digital Panel Meter. Engineered to deliver instantaneous digital readouts of voltage, current, and frequency with zero parallax viewing error and rapid sampling rates. Integrates a bright 7-segment LED display, precision analog-to-digital converter (ADC), automatic polarity indication, and flame-retardant ABS enclosure. Directly manufactured at our precision hub in Ambala Cantt (Haryana) and distributed across Punjab, Kerala, Tamil Nadu, Maharashtra, Gujarat, with exports to USA, UK, UAE, and Africa.Technical Specifications Summary
Instrument Type: Digital Panel Meter (AC/DC Options)Display Format: $3.5$ Digit / $4.5$ Digit Seven-Segment Red LEDSampling Rate: Approx. $2.5$ to $3$ samples per secondAccuracy Class: $\pm 0.5\%$ of full scale $\pm 1$ digitAuxiliary Power: $230\text{V AC} \pm 10\%$ or $110\text{V AC}$ inputManufacturing Hub: Ambala Cantt, Haryana, IndiaRole in Educational Electronics & Industry
When lab administrators and polytechnic heads in USA, UK, UAE, or Indian states like Punjab, Kerala, and Haryana search for "buy Digital Panel Meter Ambala Cantt" or "digital panel ammeter price", they demand high noise immunity. Our Digital Panel Meter is a key component of our Measuring Instruments and Electronic Devices lines. It is widely used in power supply units, trainer kits, and general testing setups across Physics Lab Equipment.Key Design & Technology Highlights
High-Visibility LED Screen
Large bright red digits ensure effortless distance reading in brightly lit or dim lab environments.
Auto Polarity & Zero Adjustment
Features internal auto-zeroing circuit and automatic negative sign display for seamless DC testing.
Standard DIN Panel Cutout
Compact $96 \times 48\text{ mm}$ standard DIN dimensions allow easy snap-in mounting into custom test benches.
Ambala Precision Assembly
Assembled in Ambala Cantt with industrial-grade microcontrollers for stable calibration over long use.
Detailed Technical Specifications
Product Name Digital Panel Meter (Voltmeter / Ammeter / Frequency Meter) Voltage Ranges 0-2V, 0-20V, 0-200V, 0-500V AC/DC Current Ranges 0-2mA, 0-200mA, 0-5A, 0-20A AC/DC Display Size $0.56\text{ inch}$ high red LED digits Input Impedance $> 10\text{ M}\Omega$ for voltage variants Operating Temp. $0^\circ\text{C}$ to $50^\circ\text{C}$ relative humidity $< 85\%$ Export & Domestic Coverage Ambala Cantt, Haryana, Punjab, Kerala, Tamil Nadu, Maharashtra, USA, UK, UAE, Africa Why Choose Our Educational Equipment?
As an established manufacturer in Ambala Cantt and exporter globally, we supply precision apparatus to institutions worldwide. Our comprehensive catalogue includes complete setups for Chemistry Lab Equipment, Biology Lab Equipment, Laboratory Plasticware, Maths Lab Equipment, and Earth Sciences.Technical Questions & Laboratory Helpdesk
1. Can a single digital panel meter measure both voltage and current simultaneously?
Dual-display models are available that show both voltage and current on separate LED lines.
2. Is an external power supply required to operate the meter?
Standard models use $230\text{V AC}$ mains auxiliary supply, while self-powered DC variants are also available.
3. What is the standard panel cutout size for installation?
The standard DIN cutout dimension is $92 \times 44\text{ mm}$ for flush panel bezel fit.
4. Can this meter be used with external current transformers (CT)?
Yes, AC current models support standard $5\text{A}$ secondary CT inputs for high current panel monitoring.
5. Do you ship Digital Panel Meters to institutions in Punjab, Kerala, USA, UK, and UAE?
Yes, we ship from Ambala Cantt to all Indian states and export globally alongside Electricity & Magnetism and Magnets.
6. Are bulk institutional discounts available for tenders?
Yes, we offer specialized wholesale pricing and tender documentation for bulk institutional orders.
7. What warranty coverage is provided with the product?
Every Digital Panel Meter comes with a 1-year operational warranty covering manufacturing defects.
Final Overview & Academic Performance Summary
Equipping your electronics bench with our Digital Panel Meter guarantees clear numerical precision and reliable performance. Whether upgrading power supply trainers or outfitting multidisciplinary labs with Anatomical Lab Models, our instruments deliver high accuracy.
Digital Panel Meter
Elevate your technical laboratory benches and industrial control panels with our high-accuracy Digital Panel Meter.
Engineered to deliver instantaneous digital readouts of voltage, current, and frequency with zero parallax viewing error and rapid sampling rates.
Integrates a bright 7-segment LED display, precision analog-to-digital converter (ADC), automatic polarity indication, and flame-retardant ABS enclosure.
Directly manufactured at our precision hub in Ambala Cantt (Haryana) and distributed across Punjab, Kerala, Tamil Nadu, Maharashtra, Gujarat, with exports to USA, UK, UAE, and Africa.
