Product Information
TECHNICAL PARAMETERS:
- Max. Speed RPM : 20000 RPM. (without Loading)
- Max. RCF Value : 22000 xg
- RPM Setting Accuracy : ±5%
- Rotor Material : Aluminum
- Construction Material : Double Walled
- Temp. Range : 0°C to 50°C ( RH Range 15% to 90%)
- Noise Level Range : ≤60 dBa ( 1 mt distance on working operation )
- Autoclavable Rotor : 121°C
- Refrigerant : CFC Free
- Refrigerator Temp. range : -20°C
- Cooling Type : Compressor Cooling System.
- Temp. Control Accuracy : ±2°C
- Insulation Material : PUF Insulated.
- Centrifuge Material : CRC Sheet Finish with Powder Coating Finish.
- Lid Material ; CRC Steel Finish with Powder Coating Finish.
- Test Tube Using Material : Polypropylene and Glass Made Tubes
- Water Drainage System : Yes
- Drive System : Direct Brushless induction drive, microprocessor controlled.
- Timer Range : 1-60min with continuous run option.
- Display & Control : Digital LCD display with Speed (RPM/RCF), temp., & time.
- Accessories : Fixed-angle rotor’s 24 x 1.5/2ml (16000 RPM)., and 2 Micro plate x 96 Wells. (3500 RPM )
- Power Supply : 220/240V, AC 50-60 Hz.
- Additional Accessories : Servo Voltage Stabilizer 2 KVA
- Warranty : 5 year’s.
- Certifications : CE & ISO 13485, ISO 9001 and 61010-2 Certification.
- Included Accessories : Spanner, Motor shaft head puller, Spare rotor nuts , 2 Nos. Fuse-, Instruction Manual Book ,Installation CD , (Corrosion resistance) oil (70009824), 3 Meter Power cord.
HIGH SPEED REFRIGERATED CENTRIFUGE (PSAW-55BL)
APPLICATION:
- Centrifugation at room temp. (ambient) is a foundational technique used across clinical, research, and industrial lab. to separate components of a mixture based on density, size, and shape, without the need for temp.-sensitive cooling.
SALIENT FEATURES:
- Bench Top Refrigerated Centrifuge general and research purpose System.
- Microprocessor based. High Speed Programmable Speed Controller.
- Automatic RPM / RCF conversion Facility.
- Timer Setting Range with Auto Cut off.
- SALIENT FEATURES
- Centrifuge supports both fixed-angle & swing-bucket rotors.
- Heavy duty C.R.C. Construction Finished with powder coating.
- SS Centrifugal bowl for extra protection and easy cleaning.
- Short run Protection.
- Swing Rotor and Fixed Angle Rotor Configuration.
- Automatic lid opening and electronic lid locking end of run.
- Corrosion-resistant, lightweight adaptors & Suitable for lab, fluid, chemical or industrial applications.
- Automatic Detection & alarms for imbalance with safety shutdown.
- Compressor off during the door open function.
- Rotors and lids high-grade metallic material (Stainless Steel)
- Fitted with well balanced brushless motor (without carbons) with electronic drive.
- 4 lines, 20 characters. Digital LCD Display, Soft touch panel for Set time, Run time, Set & RPM, RCF
- Digital Timer 1-60 min., lid lock & fast spin option and rotor Identification.
- Dynamic brake (automatic) and imbalance detector are provided.
