LAB DEEP FREEZER
Model No: PSAW-400
Description:
- A high-performance vertical double door deep freezer designed for reliable laboratory storage applications., ensuring efficient preservation of biological samples, reagents, vaccines, chemicals, & lab. materials. The vertical double-door con?guration minimizes cold air loss during access, improves energy efficiency, and allows organized storage with easy sample handling and retrieval.
Salient features:
- Suitable for Lab, Research, Pharmaceutical & Medical Storage Applications
- Pressure Equalization Port (PEP) for easy door opening after closing
- Soft touch grip for full length door handles
- Microprocessor-based 7 Segment Digital LCD Controller
- Eco-friendly Refrigerant (SNAP & F-GAS compliant) for energy efficient & eco-safe operation
- Visual & acoustic alarm system for enhanced safety & monitoring
- Adjustable temp. alarms with door ajar, service & low battery alerts
- Battery backup, remote alarm terminals & low heat output design
- Automatic Servo-Controlled Voltage Stabilizer with high /low Cut-OFF protection
- Environmentally Friendly design with Non-CFC refrigerants & PUF insulation
Product Information
QUICK SPECIFICATIONS:
- Model : PSAW-400
- Capacity : 400 Liters
- Type : Vertical Double Door
- Temperature Range : -15°C to -20°C (Settable)
- Temperature Resolution : 0.1°C
- Temperature Uniformity : ±1.4°C
- Cooling Method : Force Air Cooling
- Shelves : 5 Adjustable & Removable
- Power Supply : 230V (±10%), 50Hz, 1 Phase
- Warranty : 2 Years
- Certifications : ISO 9001 & CE Certified
Technical Parameters:
- Model : PSAW-400
- Chamber Capacity : 400 LT
- Type : Vertical Double Door Model
- Ambient Operating Condition: 30°C – 35°C
- Temp. Range : -15°C to -20°C ( Settable)
- Temp. Resolution Range : 0.1° C
- Temp. Uniformity : 1.4° C
- Noise Level : <55dBA
- Temp. Recovery : Max. 8mins after opening of door for 1min.
- Cooling method : Force Air Cooling System
- Shelves : 5 Nos. Shelves Adjustable and Removable (SS 304)
- Shelf Loading Capacity : Each Shelf Approx. 45Kg
- Compartments : 4 Nos. with Separate Hinged doors & latching arrangement.”
- Exterior Material : Pre Coated Steel With Epoxy White Finish.
- Interior Chamber Material : SS 304 Grade (Corrosion-resistant)
- Doors Features : Soft Touch Grip Handle with Lock.
- Movability Positioned : 4 Nos. Castor wheels
- Dimensions (WxDxH) : 65 x 80 x 220 CM (±10%)
- Construction : Double walled with Dual gasket (Leak proof )
- Refrigerant System : Non-CFC Refrigerant & 75mm PUF insulation
- Control System : Microprocessor-based & 7 Segment Programme Digital LCD Controller
- Defrost System : Automatic
- Light Source : LED interior lighting & external light switch
- Safety features : Battery backup for power failure
- Power Supply : 230 (±10%), AC 50Hz, Single Phase.
