PH METER (PSAW-5001)

Home PH METER (PSAW-5001)
PH METER (PSAW-5001)|PSAW

PH METER (PSAW-5001)

Model No: PSAW-5001

Research Grade Meter
pH/ORP and Temperature


Salient Features:

  • Bench-top multiparameter meter.
  • pH, Conductivity, Resistivity, ORP, ISE, and Temperature measurement.
  • Suitable for laboratory analysis of pH, ORP, ISE, EC, and temperature.
  • Expandable modular design with interchangeable measurement modules.
  • Automatic Temperature Compensation (ATC) probe included.
  • Field-upgradable measurement modules.
  • Direct, Auto-Hold, & Continuous.
  • Plug-and-play Automatic module detection.
  • pH, ORP, ISE, Conductivity (EC), and Temperature.
  • 3 Application-Specific module bays
Enquire Now

Product Information

Technical Parameters:

  • Model    : Bench-top pH meter.
  • Applications   : pH, ORP, ISE, Conductivity (EC), Resistivity, &  mp measurements.
  • System Architecture  : Expandable Modular design with interchangeable measurement modules.
  • Temperature Compensation  : Automatic Temp. Compensation ( ATC ) probe.
  • Measurement Modes  : Direct, Auto-Hold, & Continuous measurement.
  • Module Bays   : 3 Application-specific module bays.
  • Modular Expandability  : Field-upgradable modules with plug-&-play auto-recognition.
  • pH Range   : -2.000 to 20.000 pH.
  • pH Resolution   : Selectable: 0.1 / 0.01 / 0.001 pH.
  • pH Accuracy   : Up to ±0.002 pH.
  • pH Calibration   : Up to 5-point calibration; Automatic, Semi-automatic, & Manual modes.
  • Isopotential Point   : -2.000 to 20.000 pH.
  • mV Range   : -2000.0 to +2000.0 mV.
  • mV Resolution   : 1 mV / 0.1 mV.
  • mV Accuracy   : ±0.2 mV ±1 LSD.
  • mV Calibration   : Single-point offset Calibration up to ±2000.0 mV.
  • Conductivity Range  : 0.000 µS/cm to 1000.0 mS/cm.
  • Conductivity Resolution  : 0.001 µS/cm to 0.1 mS/cm (auto-ranging).
  • Conductivity Accuracy  : ±1% of reading or ±0.010 µS/cm
  • Cell Constant   : 0.0500 to 200.0000 cm?¹.
  • Conductivity Calibration  : Automatic/Manual; Single-point to 5-point calibration.
  • Temperature Range  : -20.0°C to 120.0°C.
  • Temperature Resolution  : 0.1°C.
  • Temperature Accuracy  : ±0.2°C.
  • Temperature Compensation  : pH: Automatic/Manual; Conductivity: Linear, Natural, Standard, or Disabled.
  • Reading Functions   : Direct, Auto-Hold, USP mode, Known Addition/Subtraction, and Analyte Addition/Subtraction.
  • Display    : Dual display  parameter
  • Display    : Large LCD display, minimum 7-inch.
  • User Interface   : Intuitive graphical interface with icon-based navigation.
  • Screen Configuration  : Multi-screen display for simultaneous parameter monitoring.
  • Guidance Features  : On-screen calibration, diagnostics, and setup guidance.
  • Basic View   : Measurement data, measurement profile, and stability status.
  • Simple GLP View   : Basic view with calibration Date, slope, offset (pH/ISE) and conductivity calibration status.
  • Full GLP View   : Detailed calibration records and calibration point information.
  • Graph View   : Real-time measurement vs. time graph.
  • Table View   : Measurement table updated every second.
  • Reading Stability   : Selectable Accurate, Medium, or Fast modes.
  • Sampling Rate   : 1000ms .
  • Data Logging   : Automatic, Manual, and Auto-Hold logging modes.
  • Storage Capacity   : Up to 50,000 records per file & ≥1,000,000 data points.
  • Logging Interval   : 1sec. to 180min.
  • Export Format   : CSV ( Higher-compatible format.)
  • Sample ID   : Manual incremental sample ID assignment.
  • USB Connectivity   : 2x USB-A ports & 1x USB-C port.
  • Network Connectivity  : Wi-Fi, Ethernet, FTP, Web Server, and Email support.
  • Additional Connectivity  : RS 232 port.
  • User Management   : 5 user Accounts with Administrator Access Control.
  • Data Management   : GLP-Compliant data handling with date and time stamp.
  • Calibration Reminder  : Daily, periodic, or disabled reminder settings.
  • Calibration Features  : Automatic/manual calibration, multi-point support, Automatic buffer recognition, and stability indicator.
  • Standard Accessories  : pH, ORP, ISE, EC and temp. electrodes/probes.
  • Special Probe   : Flat pH probe for Solid agar media measurement.
  • Electrode Holder   : Flexible holder with Adjustable Support arm.
  • Temp. Probe    : ATC probe Connection.
  • Included     : Cables, Connectors, User manual,  IQ/OQ/PQ Documents .
  • Accessories   : pH 4.01 ( 2 Sachets), pH 7.01 (4 sachets), pH 10.01 (2 sachets), & Electrode cleaning solution, Electrode Cleaning solution (2 sachets), pH/ORP storage solution (25 mL), 3.5 M KCl electrolyte (30 mL), Capillary pipette (1 pcs), & Electrode rinse solution ( 2 sachets).
  • Conductivity Standards  : 1413 µS/cm (4 sachets), 5000 µS/cm (2 sachets), and 12880 µS/cm (2 sachets).
  • Power Supply   : 100–240 VAC input with 24 VDC, 2 A adapter.
  • pH Buffer Standards  : NIST-traceable pH 4.01, 7.01, & 10.01 buffers; 500 mL each.
  • Additional Solutions  : Cleaning solution & electrode storage solution; 500 mL each.
  • EC Calibration Standard  : 1413 µS/cm Conductivity minimum 500 mL.
  • Calibration Certificate  : NABL-Accredited Calibration certificate.
  • Warranty    : 2 year’s
