Product Information
Short Product Description
Equip your physics laboratories and electrical testing facilities with our heavy-duty Portable Analog Wattmeter. Engineered to measure single-phase active power consumption ($W$) with high mechanical accuracy and zero electronic display delay. Features an electrodynamometer movement, anti-parallax mirrored scale, low power factor (LPF) variants, and robust wooden or ABS protective carrying case.Technical Specifications Summary
Product Name: Portable Analog WattmeterMovement Type: Electrodynamometer MechanismPower Factor: Unity Power Factor (UPF) / Low Power Factor (LPF)Current Ranges: 1A / 5A / 10A / 25A (Dual Current Coils)Voltage Ranges: 75V / 150V / 300V / 600V ACAccuracy Class: Class 0.5 / Class 1.0 High PrecisionEducational Importance & Experimental Role
When institutional buyers in USA, UK, UAE, or India search online for "buy portable analog wattmeter" or "electrodynamometer wattmeter price", they seek high coil stability and zero thermal drift. Our portable wattmeter belongs to our specialized Measuring Instruments range, engineered for demonstrating real electrical power dissipation. It integrates seamlessly into practical experiments covering Electricity & Magnetism, Electronic Devices, and core Physics Lab Equipment.Key Design & Performance Features
Electrodynamometer Accuracy
Uses air-cored fixed field coils and moving pressure coil for true power measurement.
Anti-Parallax Mirror Dial
Features a reflective mirror strip under the pointer to eliminate reading angle errors.
Portable Wooden/ABS Housing
Housed in a rugged carrying case with a protective folding cover for fieldwork and lab storage.
Multi-Range Selector Switches
Equipped with internal series/parallel links for easy voltage and current range selection.
Detailed Technical Specifications
Product Type Portable Analog Wattmeter (Single Phase) Operating Principle Electrodynamometer Type Movement Current Rating 1A / 5A (Dual range) or 5A / 10A options Voltage Rating 150V / 300V / 600V AC Selector Terminals Frequency Range 25 Hz to 125 Hz AC operational bandwidth Scale Length 140mm long high-legibility arc scale with mirror Terminal Type 4mm heavy-duty insulated safety binding posts Compliance Standards ISO & CE certified, compliant with worldwide export standards (USA, UK, UAE, Asia) Why Source Laboratory Equipment From Us?
As a trusted manufacturer and global exporter, we manufacture precision apparatus engineered for academic durability across North America, Europe, Middle East, and Asia. Our institutional catalogue covers complete lab setups including Chemistry Lab Equipment, Biology Lab Equipment, Laboratory Plasticware, Maths Lab Equipment, and Earth Sciences kits.Technical Questions & Laboratory Helpdesk
1. What is the difference between UPF and LPF portable wattmeters?
UPF (Unity Power Factor) meters are used for resistive loads ($\cos\phi = 1.0$), while LPF (Low Power Factor) meters measure inductive/capacitive loads ($\cos\phi = 0.2$).
2. Does this wattmeter measure both AC and DC power?
Electrodynamometer type wattmeters accurately measure true active power in both AC and DC electrical circuits.
3. Are patch cords included with the portable carrying case?
Yes, standard 4mm insulated laboratory connecting leads are supplied with the meter.
4. How is the scale factor calculated for multi-range models?
A multiplication factor chart is printed on the dial face for easy calculation based on selected voltage and current terminals.
5. Do you ship these meters to international university labs in USA, UK, and UAE?
Yes, we export globally alongside Heat Apparatus and Magnets.
6. Do you offer bulk institutional tender discounts?
Yes, we provide wholesale pricing and tender support documentation for institutional university orders worldwide.
7. What warranty coverage comes with the product?
Every Portable Analog Wattmeter comes with a 1-year replacement warranty against manufacturing defects.
Final Overview & Academic Performance Summary
Equipping your laboratory with our Portable Analog Wattmeter ensures precise active power measurement and long-term reliability. Whether setting up electrical engineering test benches or equipping multidisciplinary science labs with Anatomical Lab Models, our instruments deliver unmatched precision.
