Product Information
TECHNICAL PARAMETERS:
Model
PSAW-450
No need
Sample quantity
96 wellx0.2ml (Optional 96 wellx0.1m)
Temp. control method
Thermoelectronic
Consumable type
0.2 mL96 well plate (Half-skirted, Non-skirted), 8-strips tubes, Single tube (the bottom should be transparent)
Ramp rate (max)
6°C/s
Reaction volume
5-100 μl
Temp, accuracy
±0.1°C
Dynamic range
1 - 10?? copies
Temp. uniformity
≤± 0.2°C (55°C)
Sample repeatability
CV < 1%
Temp. range of hot lid
RT.+ 5°C - 110°C
Sample linear
|r|> 0.999
Temp, gradient range
0.1 - 36°C
Automatic hot lid
The hot lid can be controlled by touch button to automatically press the tube
Time increase/ decrease
0.1-9min59s, long PCR is available
Fluorescence channel
5
Time increase/ decrease
0.1 - 9.9°C touchdown PCR is available
Fluorescence dyes
F1: FAM SYBR Green 1;
F2: VIC.HEX, TET. JOE. TAMRA. CY3, NED;
F3: ROX/TexRed;
F4: CY5;
F5: CY5.5;
F6: Optional
Software function
Support absolute quantitative, relative quantitative, melting curve, HRM, SNP and other functions
Operation method
10.1 inch colourful Android touch screen, simple and convenient and Windows system computer can also connect to it
Safety Protection and Alarm
Over heat protection and alarm for block and hot lid
Excitation light source
High brightness and long-life LED excitation light source
Data export
Excel, TXT
Detector
PMT
Software language
English
Excitation wavelength
Channe1:470nm Channel2:523nm Channel3:571nm Channel4:628nm Channel5:678nm
Voltage range
100-240V
Interface mode
USB2.0/HDMI
Detection wavelength
Channel1:525nm Channel2:564nm Channel3:612nm Channel4:692nm Channel5:718nm
Power(max)
1000W
Dimension (DXWXH)
473 x 335 x 330mm
Single channel scanning time
1.5s
Net weight (kg)
26
