Product Information
Short Product Description
Equip your renewable energy and physics laboratories with our high-precision Solar Irradiance Meter (Pyranometer / Solar Power Meter). Designed to measure solar radiation flux density ($\text{W/m}^2$ or $\text{BTU}/(\text{ft}^2\cdot\text{h})$) for photovoltaic panel testing and environmental monitoring. Features a high-sensitivity silicon photodiode sensor, clear LCD digital readout, peak-hold function, and rugged ergonomic handheld casing. Directly manufactured at our scientific facility in Ambala Cantt (Haryana) and supplied across Punjab, Kerala, Tamil Nadu, Maharashtra, Gujarat, with exports to USA, UK, UAE, and Africa.Technical Specifications Summary
Instrument Model: Solar Irradiance Meter / PyranometerMeasurement Range: $0$ to $2000\text{ W/m}^2$ or $0$ to $634\text{ BTU}/(\text{ft}^2\cdot\text{h})$Sensor Type: Filtered Silicon Photodiode SensorAccuracy Class: $\pm 5\%$ or $\pm 10\text{ W/m}^2$ whichever is greaterDisplay Screen: $3.5$ Digit LCD Screen with BacklightManufacturing Hub: Ambala Cantt, Haryana, IndiaRole in Educational Physics & Renewable Energy Labs
When lab administrators and renewable energy researchers in USA, UK, UAE, or Indian states like Punjab, Kerala, and Haryana search for "buy solar irradiance meter Ambala Cantt" or "pyranometer price", they demand cosine-corrected accuracy. Our Solar Irradiance Meter is an integral part of our Measuring Instruments and Heat Apparatus product ranges. It is vital for solar panel efficiency calculations, window glass transmission testing, agricultural radiation studies, and advanced experiments in Physics Lab Equipment.Key Design & Precision Advantages
Cosine-Corrected Photodiode
Ensures accurate measurement of incident solar radiation regardless of the light angle of incidence.
Dual Unit Selection ($\text{W/m}^2$ / $\text{BTU}$)
Allows instant toggling between standard SI metric units ($\text{W/m}^2$) and imperial heat units ($\text{BTU}$).
Data Hold & Peak Memory
Features freeze-frame data hold and maximum radiation recording for field survey convenience.
Ambala Precision Manufacturing
Calibrated in Ambala Cantt under controlled optical standards for long-term field measurement stability.
Detailed Technical Specifications
Product Name Solar Irradiance Meter (Handheld Pyranometer) Spectral Response $400\text{nm}$ to $1100\text{nm}$ operational wavelength Sampling Time Approx. $0.25$ seconds per reading Power Supply Standard $9\text{V}$ PP3 transistor battery Operating Temp. $0^\circ\text{C}$ to $50^\circ\text{C}$ relative humidity $< 80\%$ Included Accessories Carrying case, protective sensor cap, and manual Export & Domestic Coverage Ambala Cantt, Haryana, Punjab, Kerala, Tamil Nadu, Maharashtra, USA, UK, UAE, Africa Why Choose Our Educational Equipment?
As an established manufacturer in Ambala Cantt and exporter globally, we supply precision apparatus to institutions worldwide. Our comprehensive catalogue includes complete setups for Chemistry Lab Equipment, Biology Lab Equipment, Laboratory Plasticware, Maths Lab Equipment, and Earth Sciences.Technical Questions & Laboratory Helpdesk
1. What is the difference between solar irradiance and solar insolation?
Solar irradiance measures instantaneous radiant power per unit area ($\text{W/m}^2$), while insolation measures total accumulated solar energy over time ($\text{kWh/m}^2$).
2. Can this meter be used to calculate solar panel efficiency?
Yes, by measuring incident solar power ($\text{W/m}^2$) alongside panel electrical output power, overall conversion efficiency can be calculated.
3. How is cosine correction beneficial during field readings?
Cosine correction compensates for light reflection errors when the sun is at low inclination angles relative to the sensor surface.
4. Is recalibration required periodically?
Annual recalibration is recommended for commercial research, though high-quality photodiode sensors maintain stability over long periods.
5. Do you ship Solar Irradiance Meters to institutions in Punjab, Kerala, USA, UK, and UAE?
Yes, we ship from Ambala Cantt to all Indian states and export globally alongside Electronic Devices and Magnets.
6. Are bulk institutional discounts available for tenders?
Yes, we offer specialized wholesale pricing and tender documentation for bulk institutional orders.
7. What warranty coverage is provided with the product?
Every Solar Irradiance Meter comes with a 1-year operational warranty covering manufacturing defects.
Final Overview & Academic Performance Summary
Equipping your physics and energy laboratory with our Solar Irradiance Meter guarantees accurate radiation measurement and reliable field performance. Whether testing photovoltaic systems or outfitting science labs with Anatomical Lab Models, our instruments deliver high accuracy.
